Motor-Window-Right Front (D3041A)

Harness-Family: Door_Front_Right

Color: BLACK

Gender: FEMALE

Part Number: 54200206

Part Description: Not Available

Connector No: D3041A

Option: Standard

Repair Kit Part Number: 05017117AA

Cavity Count: 2

Fig 1: Motor-Window-Right Front Connector End View

Courtesy of CHRYSLER

Fig 2: Motor-Window-Right Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Q22

OR/VT

PASSENGER WINDOW DRIVER (DOWN)

N/A

Q12

OR/BR

PASSENGER WINDOW DRIVER (UP)

N/A

⁽¹⁾	Pins not listed are not used for this connector
