Sensor-Front Impact-Right (D1527A)

Harness-Family: HDLP_Dash

Color: NATURAL

Gender: FEMALE

Part Number: 7283-8794-70

Part Description: A/B 040-III CONNECTOR SUB ASSEMBLY

Connector No: D1527A

Option: Standard

Repair Kit Part Number: 68065009AA

Cavity Count: 2

Fig 1: Sensor-Front Impact-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Front Impact-Right Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R82

WT/LB

0.50

RIGHT FRONT IMPACT SENSOR GROUND

N/A

R80

VT/LB

0.50

RIGHT FRONT IMPACT SENSOR SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
