Switch-Stop Lamp (D2293A)

Harness-Family: Body

Color: GRAY

Gender: FEMALE

Part Number: 4625712

Part Description: INS-WRG 6-WAY

Connector No: D2293A

Option: Standard

Repair Kit Part Number: 05183466AA

Cavity Count: 6

Fig 1: Switch-Stop Lamp Connector End View

GCWD1024343

Courtesy of CHRYSLER

Fig 2: Switch-Stop Lamp Component Location

GCWD1212067

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A924

RD

0.35

FUSED B(+)

N/A

2

L53

DG/WT

0.50

BRAKE LAMP CONTROL OUTPUT 1

N/A

3

F202

PK/GY

0.80

IGNITION RUN/START CONTROL OUTPUT

N/A

4

B16

LB/DG

0.50

BRAKE SIGNAL 2

N/A

5

Z919

BK/VT

0.80

GROUND

N/A

6

B15

DG

0.50

BRAKE SIGNAL 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
