Ring(S), Piston: Removal: Removal

WARNING: This page is about a different variant/trim than selected.
Fig 1: Piston Rings-Removing And Installing
GC0098730Courtesy of CHRYSLER GROUP, LLC
  1. Using a suitable ring expander, remove upper and intermediate piston rings.
  2. Remove the upper oil ring side rail, lower oil ring side rail and then oil ring expander from piston.
  3. Clean ring grooves of any carbon deposits.
