Ring(S), Piston: Removal: Removal

Fig 1: Piston Rings-Removing And Installing
GC0098640Courtesy of CHRYSLER GROUP, LLC
  1. Using a suitable ring expander, remove upper and intermediate piston rings.
  2. Remove the upper oil ring side rail, lower oil ring side rail and then oil ring expander from piston.
  3. Clean ring grooves of any carbon deposits.
