Switch-Seat Belt-Passenger (D2279A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1443

Part Description: INS

Connector No: D2279A

Option: Standard

Repair Kit Part Number: 05135636AA

Cavity Count: 2

Fig 1: Switch-Seat Belt-Passenger Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt-Passenger Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R58

LB/GY

0.50

PASSENGER SEAT BELT SWITCH SENSE

N/A

R60

LB/TN

0.50

PASS SEAT BELT BUCKLE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
