Switch-Window/Door Lock-Passenger (RHD) (D2302A)

Harness-Family: Door_Front_Left

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-3243-40

Part Description: KAIZEN YESC SUB ASSEMBLY

Connector No: D2302A

Option: RHD

Repair Kit Part Number: 68020743AA

Cavity Count: 8

Fig 1: Switch-Window/Door Lock-Passenger Connector End View (RHD)

Courtesy of CHRYSLER

Fig 2: Switch-Window/Door Lock-Passenger Component Location (RHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Q26

OR/GY

MASTER WINDOW SWITCH RIGHT FRONT (DOWN)

N/A

Q21

OR/WT

DRIVER WINDOW DRIVER (DOWN)

N/A

Q11

OR/LG

DRIVER WINDOW DRIVER (UP)

N/A

Q15

OR/RD

WINDOW LOCK OUT SWITCH OUTPUT

N/A

F981

PK/YE

FUSED IGNITION RUN/ACCESSORY CONTROL OUTPUT

N/A

P696

LG/WH

0.35

PASSENGER DOOR LOCK SWITCH MUX

N/A

Z924

BK/LB

0.50

GROUND

N/A

Q16

OR/BG

MASTER WINDOW SWITCH RIGHT FRONT (UP)

N/A

⁽¹⁾	Pins not listed are not used for this connector
