Connector End Views & Electrical Component Locations (2 Of 3): S338
Harness-Family: Seat_Left
Color: NA
Gender: FEMALE
Part Number: TBD
Part Description: Not Available
Connector No: S1
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count: null
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | Z908 | BK/GY | 14 | GROUND | N/A | ||
| 2 | Z960 | BK/LB | 12 | GROUND | N/A | ||
| 3 | Z960 | BK/LB | 0.80 | GROUND | N/A | ||
| 4 | Z960 | BK/LB | 16 | GROUND | N/A | ||
| 5 | Z960 | BK/LB | 0.80 | GROUND | N/A | ||
|
|||||||
