Sensor-Oxygen 1/1 (D1539A)

Harness-Family: Powertrain

Color: NATURAL

Gender: MALE

Part Number: 184346-2

Part Description: 2 X 2 CAP ASSEMBLY, KEY A-C3

Connector No: D1539A

Option: Standard

Repair Kit Part Number: 05161922AA

Cavity Count: 4

Fig 1: Sensor-Oxygen 1/1 Connector End View

GCWD1080966

Courtesy of CHRYSLER

Fig 2: Sensor-Oxygen 1/1 Component Location

GCWD1211957

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z909

BK

0.50

GROUND

2.0L

2

K99

BR/LG

0.50

O2 1/1 HEATER CONTROL

2.0L

3

K902

BR/DG

0.80

O2 RETURN (UPSTREAM)

N/A

4

K41

DB/LB

0.80

O2 1/1 SIGNAL

2.0L

⁽¹⁾	Pins not listed are not used for this connector
