Sensor-Wheel Speed-Abs-Left Front (D1572A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 7287-1598-30

Part Description: 2P 1.5 YESC RP SLD (WHEEL SPEED) W/ CPA

Connector No: D1572A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Sensor-Wheel Speed-ABS-Left Front Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Wheel Speed-ABS-Left Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

DG/LG

0.50

LEFT FRONT WHEEL SPEED SENSOR (+)

N/A

DG/TN

0.50

LEFT FRONT WHEEL SPEED SENSOR (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
