Motor-Seat Adjuster-Driver Horizontal (LHD) (D3024A)

Harness-Family: Seat_Left

Color: GRAY

Gender: FEMALE

Part Number: 1326490-3

Part Description: 4P RECEPTACLE HOUSING - 2X JPT + 2X MT3

Connector No: D3024A

Option: LHD

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Motor-Seat Adjuster-Driver Horizontal Connector End View (LHD)

Courtesy of CHRYSLER

Fig 2: Motor-Seat Adjuster-Driver Horizontal Component Location (LHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P15

LG/WT

DRIVER SEAT HORIZONTAL FORWARD DRIVER

N/A

P17

LG/DG

DRIVER SEAT HORIZONTAL REARWARD DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
