Handle, Exterior: Installation: Installation

Fig 1: Exterior Handle

Courtesy of CHRYSLER GROUP, LLC

Connect the electrical connector (2).
Connect release cable to the handle.
Align handle studs to the holes in the liftgate and install handle (1).
Install six nuts to handle studs and tighten to 8.5 N.m (75 in. lbs.).

Fig 2: Lower Liftgate Trim
Courtesy of CHRYSLER GROUP, LLC
Install the lower liftgate trim (3). Refer to PANEL, TRIM, INSTALLATION .
