CLOCKSPRING C2 (D6654B)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1438466-2

Part Description: 4 POS PLUG HOUSING, LEFT KEYED

Connector No: D6654B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Clockspring C2 Connector End View

GCWD1024801

Courtesy of CHRYSLER

Fig 2: Clockspring C2 Component Location

GCWD1160681

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

D65

WH/BK

0.35

CAN C (+)

N/A

2

D64

WH/LB

0.35

CAN C (-)

N/A

3

Z912

BK

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
