Sensor-Side Impact-Left 2 (D1529A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 7283-8794-70

Part Description: A/B 040-III CONNECTOR SUB ASSEMBLY

Connector No: D1529A

Option: Standard

Repair Kit Part Number: 68065009AA

Cavity Count: 2

Fig 1: Sensor-Side Impact-Left 2 Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact-Left 2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R19

LG/WT

0.35

LEFT SIDE IMPACT SENSOR 2 GROUND

N/A

R17

LG/LB

0.35

LEFT SIDE IMPACT SENSOR 2 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
