Lamp-Assembly Tail-Right C1 (MK74 Export) (D6642A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: ZFI-07054-UO

Part Description: Not Available

Connector No: D6642A

Option: MK74 EXPORT

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Assembly Tail-Right C1 Connector End View (MK74 Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly Tail-Right C1 Component Location (MK74 Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z924

BK/WT

0.80

GROUND

N/A

L62

WT/YL

0.50

RIGHT REAR TURN LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
