Lamp-Dome 2 (D4639A)

Harness-Family: Headliner

Color: BLACK

Gender: FEMALE

Part Number: 1384

Part Description: INSULATOR 3 WAY

Connector No: D4639A

Option: Standard

Repair Kit Part Number: 68057308AA

Cavity Count: 3

Fig 1: Lamp-Dome 2 Connector End View

GCWD1016831

Courtesy of CHRYSLER

Fig 2: Lamp-Dome 2 Component Location

GCWD1211865

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

2

M24

YE/WH

0.35

COURTESY LAMPS DRIVER

N/A

3

Z911

BK

0.35

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
