Lamp-Fog-Right Front (MK49) (D4532A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 12124819_12020807

Part Description: Not Available

Connector No: D4532A

Option: MK49

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Lamp-Fog-Right Front Connector End View (MK49)

Courtesy of CHRYSLER

Fig 2: Lamp-Fog-Right Front Component Location (MK49)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L89

WT/YL

LEFT FRONT FOG LAMP CONTROL

N/A

Z909

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
