Lamp-Fog-Right Front (MK74) (D4532A)

Harness-Family: HDLP_Dash

Color: NATURAL

Gender: FEMALE

Part Number: F750200

Part Description: 2W 1.5 GTS2 Female CONNECTOR

Connector No: D4532A

Option: MK74

Repair Kit Part Number: 68080449AA

Cavity Count: 2

Fig 1: Lamp-Fog-Right Front Connector End View (MK74)

Courtesy of CHRYSLER

Fig 2: Lamp-Fog-Right Front Component Location (MK74)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L90

WT/OR

0.50

RIGHT FRONT FOG LAMP CONTROL

N/A

Z909

0.50

GROUND

N/A

L90

WT/OR

0.50

RIGHT FRONT FOG LAMP CONTROL

N/A

Z909

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
