Lamp-Side Repeater-Left (D4575A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 34062-0047

Part Description: Not Available

Connector No: D4575A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Side Repeater-Left Connector End View

GCWD1006548

Courtesy of CHRYSLER

Fig 2: Lamp-Side Repeater-Left Component Location

GCWD1211931

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

L161

WT/LG

0.50

LEFT FRONT TURN SIGNAL CONTROL

N/A

2

Z923

BK/LB

0.80

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
