Latch-Door-Passenger (Export) (D6615A)

Harness-Family: Door_Front_Left

Color: BLACK

Gender: FEMALE

Part Number: 805-031-501

Part Description: 8POL MLK KUPPLUNG ELA 2 REIHIG

Connector No: D6615A

Option: EXPORT

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Latch-Door-Passenger Connector End View (Export)

Courtesy of CHRYSLER

Fig 2: Latch-Door-Passenger Component Location (Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P237

DG/BG

0.50

SECONDARY UNLOCK DRIVER

N/A

P235

LG/BG

0.50

SECONDARY LOCK DRIVER

N/A

P240

BG/WH

0.50

PASSENGER DOOR UNLOCK DRIVER

N/A

P33

BG/DB

0.50

DOOR LOCK DRIVER

N/A

G75

VT/DB

0.50

DRIVER DOOR AJAR SWITCH SENSE

N/A

Z924

BK/LB

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
