Mirror-Inside Rearview (Premium) (D6625A)

Harness-Family: A_Pillar

Color: BLACK

Gender: FEMALE

Part Number: 917981-2

Part Description: 040/070 HYBRID I/O CONNECTOR MK-II

Connector No: D6625A

Option: PREMIUM

Repair Kit Part Number: Not Available

Cavity Count: 16

Fig 1: Mirror-Inside Rearview Connector End View (Premium)

Courtesy of CHRYSLER

Fig 2: Mirror-Inside Rearview Component Location (Premium)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X712

DG/LB

0.35

MICROPHONE 1 IN (+)

N/A

X792

LB/DG

0.35

MICROPHONE IN (-)

N/A

X722

LB/DG

0.35

MICROPHONE 2 IN (+)

N/A

Z912

0.80

GROUND

N/A

X835

OR/GY

0.35

SENSOR GROUND

N/A

X793

DG/YL

0.35

MICROPHONE FEED

N/A

⁽¹⁾	Pins not listed are not used for this connector
