Relay-Trailer Tow-Left Turn (MK74) (D818A)

Harness-Family: Trailer_Tow

Color: GRAY

Gender: FEMALE

Part Number: 12129716

Part Description: 4WAY BLACK METRI-PACK 280 SEALED

Connector No: D818A

Option: MK74

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Relay-Trailer Tow-Left Turn Connector End View (MK74)

Courtesy of CHRYSLER

Fig 2: Relay-Trailer Tow-Left Turn Component Location (MK74)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L615

WT/LB

0.80

TRAILER TOW LEFT STOP/TURN SIGNAL

N/A

Z960

BK/LB

0.80

GROUND

N/A

L63

DG/RD

0.50

LEFT REAR TURN LAMP DRIVER

N/A

A100

RD/VT

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
