Sensor-Crankshaft Position (D1511A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: F519600

Part Description: Not Available

Connector No: D1511A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Sensor-Crankshaft Position Connector End View
GCWD1006356Courtesy of CHRYSLER
Fig 2: Sensor-Crankshaft Position Component Location
GCWD1212026Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 F855 PK/YL 0.50 5 VOLT SUPPLY N/A
2 K925 DB/GY 0.50 CKP GROUND N/A
3 K24 BR/LB 0.50 CKP SIGNAL N/A
(1) Pins not listed are not used for this connector
