Sensor-Intake Air Temperature (D1503A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: 33214-0002

Part Description: Not Available

Connector No: D1503A

Option: Standard

Repair Kit Part Number: 05017119AA

Cavity Count: 2

Fig 1: Sensor-Intake Air Temperature Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Intake Air Temperature Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K21

DB/LG

0.50

IAT SIGNAL

N/A

K915

BR/WT

0.50

SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
