Sensor-Side Impact Pressure-Left (D1548A)

Harness-Family: Door_Front_Left

Color: BLACK

Gender: FEMALE

Part Number: 7287-0027-30

Part Description: 2P 1.5MM YESC (5.0MM PITCH) SUB-ASSEMBLY

Connector No: D1548A

Option: Standard

Repair Kit Part Number: 68064995AA

Cavity Count: 2

Fig 1: Sensor-Side Impact Pressure-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact Pressure-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R130

0.50

LEFT SIDE IMPACT PRESSURE SENSOR SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
