Switch-Ignition (D2250A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 54200517

Part Description: Not Available

Connector No: D2250A

Option: Standard

Repair Kit Part Number: 05017124AB

Cavity Count:

Fig 1: Switch-Ignition Connector End View

GCWD1013971

Courtesy of CHRYSLER

Fig 2: Switch-Ignition Component Location

GCWD1160660

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z912

BK

0.50

GROUND

N/A

2

G20

VT/BR

0.35

IGNITION SWITCH SENSE

N/A

3

F20

PK/WH

0.35

IGNITION RUN/START CONTROL OUTPUT

N/A

5

A952

RD

0.35

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
