Switch-Window/Door Lock-Driver C2 (RHD) (D2300B)

Harness-Family: Door_Front_Right

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-3243-40

Part Description: KAIZEN YESC SUB ASSEMBLY

Connector No: D2300B

Option: RHD

Repair Kit Part Number: 68020743AA

Cavity Count: 8

Fig 1: Switch-Window/Door Lock-Driver C2 Connector End View (RHD)

Courtesy of CHRYSLER

Fig 2: Switch-Window/Door Lock-Driver C2 Component Location (RHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F981

PK/BR

FUSED IGNITION RUN/ACCESSORY CONTROL OUTPUT

N/A

Z923

0.50

GROUND

N/A

Z919

BK/LB

GROUND

N/A

Q15

OR/RD

WINDOW LOCK OUT SWITCH OUTPUT

N/A

Q26

OR/GY

MASTER WINDOW SWITCH RIGHT FRONT (DOWN)

N/A

Q16

OR/BG

MASTER WINDOW SWITCH RIGHT FRONT (UP)

N/A

P697

LG/DG

0.50

DOOR LOCK SWITCH MUX

N/A

⁽¹⁾	Pins not listed are not used for this connector
