Actuator-RECIRCULATION Door (D10A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 13579375

Part Description: MICRO HVT UNSEALED Female CONNECTOR

Connector No: D10A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Actuator-Recirculation Door Connector End View

Courtesy of CHRYSLER

Fig 2: Actuator-Recirculation Door Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C32

DB/BG

0.35

RECIRCULATION DOOR DRIVER

LHD

C34

DB/LB

0.35

COMMON DOOR DRIVER

N/A

C32

DB/BG

0.35

RECIRCULATION DOOR DRIVER

RHD

⁽¹⁾	Pins not listed are not used for this connector
