Airbag-Side Curtain-Left (D3083A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: F760510

Part Description: Not Available

Connector No: D3083A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Airbag-Side Curtain-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Airbag-Side Curtain-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

LB/WT

0.50

LEFT CURTAIN SQUIB 1 LINE 2

N/A

LB/OR

0.50

LEFT CURTAIN SQUIB 1 LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
