BACKLITE-Electric Heated C2 (D7403B)

Harness-Family: Liftgate

Color: BLACK

Gender: FEMALE

Part Number: 7123-5014-30

Part Description: INSULATOR

Connector No: D7403B

Option: Standard

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Backlite-Electric Heated C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Backlite-Electric Heated C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C515

BU/OG

REAR WINDOW DEFOGGER RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
