Horn 1 (D5905A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 7123-5014-30

Part Description: INSULATOR

Connector No: D5905A

Option: Standard

Repair Kit Part Number: 68018942AA

Cavity Count: 1

Fig 1: Horn 1 Connector End View

GCWD1014523

Courtesy of CHRYSLER

Fig 2: Horn 1 Component Location

GCWD1160755

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X21

GY/YL

0.50

FUSED HORN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
