Injector-Fuel 2 (D5215A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: 34062-0047

Part Description: Not Available

Connector No: D5215A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Injector-Fuel 2 Connector End View

GCWD1006548

Courtesy of CHRYSLER

Fig 2: Injector-Fuel 2 Component Location

GCWD1211927

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K12

BR/DB

0.50

INJECTOR CONTROL 2

N/A

2

F343

BR/YL

0.50

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
