Lamp-Assembly Tail-Left C1 (MK74 Export) (D6641A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 7900-1493-006

Part Description: USCAR 3WAY SIDE LATCH CONNECTOR ASSEMBLY

Connector No: D6641A

Option: MK74 EXPORT

Repair Kit Part Number: 68030097AA

Cavity Count: 3

Fig 1: Lamp-Assembly Tail-Left C1 Connector End View (MK74 Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly Tail-Left C1 Component Location (MK74 Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z921

BK/LB

0.80

GROUND

N/A

L63

DG/RD

0.50

LEFT REAR TURN LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
