Lamp-Assembly Tail-Right C4 (MK49 Export) (D6642D)

Harness-Family: Rear_Fog

Color: BLACK

Gender: FEMALE

Part Number: EEM0412

Part Description: Not Available

Connector No: D6642D

Option: MK49 EXPORT

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Assembly Tail-Right C4 Connector End View (MK49 Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly Tail-Right C4 Component Location (MK49 Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z905

0.80

GROUND

N/A

L239

WT/DG

0.80

REAR FOG LAMP RELAY CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
