Lamp-Assembly-Left Front C1 (Export) (D6605A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 172236-2

Part Description: Not Available

Connector No: D6605A

Option: EXPORT

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Assembly-Left Front C1 Connector End View (Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C1 Component Location (Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L33

WT/LG

0.50

LEFT HIGH BEAM DRIVER

N/A

L43

WT/DB

0.50

LEFT LOW BEAM DRIVER

N/A

Z906

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
