Lamp-Assembly-Left Front C2 (MK49) (D6605B)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 12124819_12020807

Part Description: Not Available

Connector No: D6605B

Option: MK49

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Lamp-Assembly-Left Front C2 Connector End View (MK49)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C2 Component Location (MK49)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L43

WT/DB

0.50

LEFT LOW BEAM DRIVER

N/A

Z906

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
