Lamp-Assembly-Left Front C2 (MK74) (D6605B)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 09 4412 11

Part Description: RECEPTACLE HOUSING 2 X SLK 2.8 ELA

Connector No: D6605B

Option: MK74

Repair Kit Part Number: 68032275AB

Cavity Count: 2

Fig 1: Lamp-Assembly-Left Front C2 Connector End View (MK74)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C2 Component Location (MK74)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z906

0.50

GROUND

N/A

WT/YL

0.50

PARK LAMP RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
